Description

Antal 60mm Mast Block Single Sheave

Technical Description Features Metric American Length (L) 5.12 in 130 mm Width (W) 1.16 in 29.5 mm Height (H) 1.93 in 49 mm Ø sheave (D) 2.36 in 60 mm Side bearing – Delrin balls Weight 0.33 lb 150 g Ø max line 0.47 in 12 mm A 3.23 in 82 mm B 0.91 in 23 mm SWL 1763.7 lb 800 kg Material – Aluminum Sheave material – Resin Fixing screws 0.08 x 0.24 in 2 x Ø6 mm
