Description
Harken 76mm Deck Sheave
Big Boat sheaves are available for special applications as well as for replacement sheaves in Big Boat blocks. Made of hardcoat-anodized, PTFE-impregnated 6061-T6 aluminum, sheaves feature Torlon rollers tocarry high radial loads and carbon-black Delrin balls to support sideloads and provide UV protection. Delrin is a registered trademark of E. I. du Pont de Nemours and Company or its affiliates. Torlon is a registered trademark of Solvay Advanced Polymers L.L.C.
Technical Description
| Sheave Ø (mm) | 76 mm |
| Sheave Ø (in) | 3 in |
| Width (mm) | 22 mm |
| Width (in) | 7/8 in |
| Weight (g) | 170 g |
| Weight (oz) | 6 oz |
| Maximum line Ø (mm) | 14 mm |
| Maximum line Ø (in) | 9/16 in |
| Fasteners (mm) | 10 mm |
| Fasteners (in) | 3/8 in |
| Center pin Ø (mm) | 10 mm |
| Center pin Ø (in) | 3/8 in |
| Maximum working load (kg) | 2245 kg |
| Maximum working load (lb) | 4950 lb |
| Breaking load (kg) | 4490 kg |
| Breaking load (lb) | 9900 lb |
