Description

Please call us to confirm availability.

The Atlantic Portlight has clean lines and a clear, acrylic window housed in an attractive aluminium frame.

• Extensive range
• Flyscreens provided as standard
• Friction hinges
• Screw handles available as an option
• Full range of spare parts available

Manufacturer part #: 39110090

Technical Description Features American Metric Hull Valance Thin Thin Version Opening Opening Acrylic Colour Smoke Grey Smoke Grey Frame Colour Silver Silver Hatch Weight 3.5 in 1.6 kg Acrylic Window Thickness 5/16 in 8 mm Overall Width X 6- 7/8 in 174 mm Overall Length Y 12 in 304 mm Overall Height Z 1/4 in 6 mm Overall Radii R 2- 13/16 in 71 mm Cut-Out Width X1 6- 1/16 in 154 mm Cut-Out Length Y1 11- 3/16 in 284 mm Cut-Out Radii R1 2- 3/8 in 61 mm
