Description
Manufacturer part #: H8
| Features | American | Metric | Description | H8 Halyard Shackle |
|---|---|---|
| Overall Length (A) | 3.15 in | 80 mm |
| Overall Width (B) | 1.315 in | 33.4 mm |
| Ear Thickness (C ) | 0.281 in | 7.1 mm |
| Overall Throat Length (D) | 1.50 in | 38.1 mm |
| Effective Throat Length (E ) | 0.85 in | 21.6 mm |
| Inside Throat Width (F) | 0.76 in | 19.3 mm |
| Thimble Groove Width (G) | 0.56 in | 14.2 mm |
| Overall Ear Height (H) | 1 in | 25.4 mm |
| Overall Thimble Heigth (I) | 1.06 in | 26.9 mm |
| Pin Minimun Diameter (J) | 0.32 in | 8.1 mm |
| Line Size | 3/8 – 1/2 in | 10 – 12 mm |
| Weight | 3.1 oz | 87.7 g |
| Working Load | 4000 lb | 1818 kg |
| Breaking Strength | 8000 lb | 3636 kg |
Manufacturer part #: H8
Tylaska’s halyard shackles have the highest strength-to-weight ratio of any existing halyard shackle on the market. A captive 17 – 4 PH stainless pin makes for trouble-free operation. The all-metal machined line thimble allows for use as a 2 – 1 purchase without the wear or melting that occurs with plastic molded thimbles. Lines can also be permanently spliced for a fixed halyard.
